lmages are for reference only.

HCPL-4100

Manufacturer
Manufacturer Product Number

HCPL-4100

Description

OPTOISO 3.75KV TRNSMTR 8DIP

Detailed Description

Optoisolator Current Loop Transmitter 3750Vrms 1 Channel 8-DIP

Datasheet
Stock Availability

Please contact sales@vihochips.com

QUANTITY

Product Attributes

TYPE DESCRIPTION
Category Special Purpose Isolators
Packaging Tube
Type Current Loop Transmitter
Number of Channels 1
Voltage - Isolation 3750Vrms
Common Mode Transient Immunity (Min) 1kV/µs
Input Type Logic
Current - Output / Channel 30mA
Propagation Delay tpLH / tpHL (Max) 1.6µs, 1µs
Rise / Fall Time (Typ) 16ns, 23ns
Voltage - Supply 4.5V ~ 20V
Operating Temperature -40°C ~ 85°C
Mounting Type Through Hole
Package / Case 8-DIP (0.300", 7.62mm)
Supplier Device Package 8-DIP
Approval Agency CSA, UR
Base Product Number HCPL-4100

Environmental & Export Classifications

ATTRIBUTE DESCRIPTION
RoHS Status ROHS3 Compliant
Moisture Sensitivity Level (MSL) 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8541.49.8000

Additional Resources

ATTRIBUTE DESCRIPTION
Other Names 516-1148-5
Standard Package 50
